Van điện từ 5V310-08

Van điện từ 5V310-08

Van điện từ 5V310-08

Thông số kỹ thuật van điện Airtac 5V310-08:

Van điện từ 5V310-08 5V320-08 5V330-08
Van điện từ 5V310-10 5V320-10 5V330-10
Van điện từ 5V410-15 5V420-15
Van điện từ 5V430-15 5V Series Electrical Solenoid Valve

Model: Van điện 5V110-M5 Van điện 5V120-M5 Van điện 5V130-M5 Van điện 5V110-06 Van điện 5V120-06 Van điện 5V130-06
Port size: In=Out=Exhaust=M5 In=Out=Exhaust=1/8″
Orifice Size: 5.5mm² 5.0mm² 12.0mm² 9.0mm²
Cv Valve: 0.31 0.28 0.67 0.50
Weight:(g) 120 175 200 120 175g 200
Valve Type: 5 port 2 position 5 port 3 position 5 port 2 position 5 port 3 position
Model: 5V210-06 5V220-06 5V230-06 5V210-08 5V220-08 5V230-08
Port size: In=Out=Exhaust=1/8″ In=Out=1/4″ Exhaust=1/8″
Orifice Size: 14.0mm² 12.0mm² 16.0mm² 12.0mm²
Cv Valve: 0.78 0.67 0.89 0.67
Weight: 220g 320g 360g 220g 320g 360g
Valve Type: 5 port 2 position 5 port 3 position 5 port 2 position 5 port 3 position
Model: 5V310-08 5V320-08 5V330-08 5V310-10 5V320-10 5V330-10
Port size: In=Out=Exhaust=1/4″ In=Out=3/8″ Exhaust=1/4″
Orifice Size: 30.0mm² 18.0mm² 36.0mm² 21.5mm²
Cv Valve: 1.68 1.00 2.00 1.20
Weight: 310g 400g 450g 310g 400g 450g
Max Frequency: 5Cycle/Sec 3Cycle/Sec 5Cycle/Sec 3Cycle/Sec
Valve Type: 5 port 2 position 5 port 3 position 5 port 2 position 5 port 3 position
Model: 5V410-15 5V420-15 5V430-15
Port size: In=Out=Exhaust=1/2″
Orifice Size: 50.0mm² 30.0mm²
Cv Valve: 2.79 1.68
Weight: 590 720 770
Max Frequency: 3Cycle/Sec
Valve Type: 5 port 2 position 5 port 3 position
Fluid: Air(to be filtered by 40μm filter element)
Acting: Internal pilot
Operating Pressure: 0.15~0.8MPa(21~114psi)
Proof Pressure: 1.2MPa(175psi)
Temperature: -20~70℃
Material of Body: Aluminum Alloy
Lubrication: Not Required
van dien 5V310-08
